IPC-6012D Qualification and Performance Specification for Rigid Printed Boards - Download

SKU: 6012-STD-0-D-0-EN-D

NOTE: This Product is Downloadable Only. Single User License, Non-printable and Non-Device Transferable . Requires eMail address and contact information of End User.

This specification covers qualification and performance of rigid printed boards, including single-sided, double-sided, with or without plated-through holes, multilayer with or without blind/buried vias and metal core boards. It addresses final finish and surface plating coating requirements, conductors, holes/vias, frequency of acceptance testing and quality conformance as well as electrical, mechanical and environmental requirements.

Revision D incorporates many new requirements in areas such as HASL coatings, alternative surface finishes, edge plating, marking, microvia capture and target lands, copper cap plating of filled holes, copper filled microvias and dielectric removal. For use with IPC-6011. Supersedes IPC-6012C and IPC-6016

IMPORTANT: Single-Device DRM-Protected Document
This document has single-device/user digital rights management (DRM) protection. This document will only be accessible by a single user on a single device. If you are purchasing this DRM-protected document for another user, you will need to provide contact information for that user when placing your order.

$84.00
