The Component Identification Training & Reference Guide is a valuable tool for employee training and quick reference. This comprehensive component identification resource for electronics assembly operators and inspectors contains color photographs, computer graphics, schematic symbols and detailed descriptions of more than 50 common through-hole and surface mount components used in electronics assembly today.

The new Revision J contains updated info on SSOP, TSOP, QFP, LQFP, PQFP, LCC, QFN, and BGA-related packages, including all the variations within those groups.

New components include DFN, QFN – Multi Row, PoP (Package on Package), CSP (ChipScale Package), COB (Chip on Board), Bare Die and...

This Addendum supplements or replaces specifically identified requirements of IPC J-STD-001, Revision G, for soldered electrical and electronic assemblies that must survive the vibration and thermal cyclic environments of getting to and operating in space. 28 pages.  Released April 2018.

This updated full-color, 18 x 24-inch wall poster visually defines minimum/maximum Class 3 through hole solder joint acceptability requirements from Revision G of the IPC-A-610 industry standard, Acceptability of Electronic Assemblies. Containing high-quality computer graphics, this poster depicts complex through hole solder joint requirements so clearly, that all operators and inspectors can easily understand and apply this important criteria.

Bring technically accurate, industry-consensus acceptability standards to your training room or inspection area with this visual learning and reference tool. Product includes one poster, for Class 3.

This updated full-color, 18 x 24-inch wall poster visually defines minimum/maximum Class 2 through hole solder joint acceptability requirements from Revision G of the IPC-A-610 industry standard, Acceptability of Electronic Assemblies. Containing high-quality computer graphics, this poster depicts complex through hole solder joint requirements so clearly, that all operators and inspectors can easily understand and apply this important criteria.

Bring technically accurate, industry-consensus acceptability standards to your training room or inspection area with this visual learning and reference tool. Product includes one poster, for Class 2.

Three updated full-color, 18 x 24-inch laminated wall posters visually define minimum/maximum Class 3 surface mount solder joint acceptability requirements from Revision G of the IPC-A-610 industry standard, Acceptability of Electronic Assemblies. Containing high-quality computer graphics, each poster depicts surface mount solder joint requirements so clearly, that operators and inspectors can easily understand and apply this important criteria. Bring technically accurate, industry-consensus acceptability standards to your training room or inspection area with these visual learning and reference tools.

This three-poster set includes one poster each for Class 3 Chip, Gull Wing and J-Lead component requirements.

Three updated full-color, 18 x 24-inch laminated wall posters visually define minimum/maximum Class 2 surface mount solder joint acceptability requirements from Revision G of the IPC-A-610 industry standard, Acceptability of Electronic Assemblies. Containing high-quality computer graphics, each poster depicts surface mount solder joint requirements so clearly, that operators and inspectors can easily understand and apply this important criteria. Bring technically accurate, industry-consensus acceptability standards to your training room or inspection area with these visual learning and reference tools.

This three-poster set includes one poster each for Class 2 Chip, Gull Wing and J-Lead component requirements.

The officially recognized "Lead Free" soldering certification training kit for IPC-7711/7721 Revision "C" operator (CIS) certification. This kit contains a variety of components in lead free format to allow for the evaluation and testing of students for not only initial certification, but also recertification.

Includes optional components and features such as SMT tantalum caps and 0201 resistors, inner layer and multi-layer repair sections, conformal coating section, damaged surface conductors ready for repair and components with adhesive staking.  Includes one (1) lead free assembled board and one (1) set of lead free components.

Contains the following materials (in "Lead Free"):
(1) Fully...

The officially recognized soldering certification training kit for IPC-7711/7721 Revision "C" operator (CIS) certification. This kit contains a variety of components to allow for the evaluation and testing of students for not only initial certification, but also recertification.

Includes optional components and features such as SMT tantalum caps and 0201 resistors, inner layer and multi-layer repair sections, conformal coating section, damaged surface conductors ready for repair and components with adhesive staking.  Includes one (1) assembled board and one (1) set of components.

Contains the following materials:
(1) Fully Assembled Board
(6) 1/4 Watt Resistor
(6) 16 Lead Dip
(6) T05/39 Transistor
(6) Transistor Standoff
(6) CK06...

This Addendum supplements or replaces specifically identified requirements of IPC-6012D, Revision D, for rigid printed boards that must survive the vibration, ground testing and thermal cyclic environments of space and military avionics.

Looking to sharpen your soldering skills with a more realistic soldering production training kit?  Look no further. This through hole soldering kit comes with two practice boards and double, and in some cases triple, the number of components to assemble, so you can solder and hone those skills. The components are guaranteed solderable and shipped in static shielded bags. Buy one kit and share in a class, with plenty of components to practice with.

Contains the following materials:
(2) Through Hole Technology Boards
(10) Axial Diodes
(4) Electrolytic Capacitors
(20) CKO6 Capacitors with Stand-offs
(20) 1/4 Watt Resistors
(12) 1/2 Watt Resistors
(6) 16 Pin DIP ICs
(10)...

Now Available!

IPC's J-STD-001 is recognized worldwide as the sole industry-consensus standard covering soldering materials and processes. This revision includes support for both traditional solder alloys and for lead-free manufacturing.

Whenever possible, the criteria descriptions have been adjusted to make them easier to understand for materials, methods and verification for producing quality soldered interconnections and assemblies.

 Some Significant Changes to 001G:

    •    The "International Space Station Symbol" Replaces the "Space Shuttle Symbol" Throughout the Document
    •    General Section Scope and Purpose were Re-evaluated and Updated
    •    General Section New Section on Objective
    •    Improved language for ease...

Now Available!

IPC-A-610 is the most widely used electronics assembly standard in the world. A must for all quality assurance and assembly departments, IPC-A-610G illustrates industry-accepted workmanship criteria for electronics assemblies through detailed statements reflecting acceptable and defect conditions, supported by full-color photographs and illustrations. Additionally, wherever possible statements were modified to make readability easier and to enhance understanding — all without eliminating any requirements.

Some significant changes to 610G:

    •    The Standard Remains a Visual Quality Acceptance Standard
    •    In the General Section – Significant Changes Were Made to Various Topics
    •    Various Updates...

Updated to Revision C of the IPC/WHMA-A-620, this Training & Reference Guide illustrates the critical acceptance criteria for Wire Harness Assembly -- all in a convenient and compact 5.5 x 8.5 inch (14 x 21.5 cm) size.

DRM-WHA-C explains the basic acceptance criteria for wire harness assemblers, crimp operators, and QA personnel. This handy reference and training tool is a great way to help explain the most important requirements from the industry standard on Wire Harness Acceptability, IPC/WHMA-A-620C. Using easy-to-understand computer-generated graphics and language geared toward factory-level employees, this guide will help insure that your company products meet the required...

IPC/WHMA-A-620 remains the only industry-consensus standard for Requirements and Acceptance of Cable and Wire Harness Assemblies. IPC and the Wire Harness Manufacturers Association (WHMA) continued to work together to develop this significant update.

The standard has over 700 full-color pictures and illustrations. Included in the 19 chapters are criteria for wire prep, soldering to terminals, crimping of stamped and formed contacts and machined contacts, insulation displacement connectors, ultrasonic welding, splicing, connectors, molding, marking, coax/biax cables, wrapping/lacing, shielding, assembly and wire-wrap terminations.

Also covered are the criteria for molding, potting, splicing, crimp contacts without insulation support, inline insulation displacement connectors, connectorization,...

This guide includes everything needed for repair and rework of electronic assemblies and printed circuit boards! IPC-7711B/7721C Rework, Modification and Repair of Electronic Assemblies has received a complete procedure by procedure update to assure applicability to both lead free and traditional SnPb soldered assemblies. Included in this revision are the procedures previously released as change pages, an updated general information and common procedures section, new procedures for BGAs using focused IR Reflow Systems with integral preheater and general updates to all other procedures.

Part 1 General Requirements has also been updated for ease of use and provides important direction and...

The definitive illustrated guide to printed board acceptability! This four-color document provides photographs and illustrations of the target, acceptable and nonconforming conditions that are either internally or externally observable on bare printed boards. Make sure your operators, inspectors, and engineers have the most current industry consensus information. With 120 new or revised photographs and illustrations, revision J provides new coverage on topics such as microvia contact dimensions, plating, voiding and fill, along with updated and expanded coverage for dielectric removal (etchback, smear and wicking), plating folds, surface plating for edge connectors, SMT and BGA pads, marking, hole registration, delamination, cap...

IPC J-STD-001F is recognized worldwide as the sole industry-consensus standard covering soldering materials and processes. This revision includes support for both traditional solder alloys and for lead-free manufacturing. Examples of some of the significant changes are revision to plated-through hole, PTH, minimum fill requirements; criteria for two new SMT termination types; and expanded conformal coating criteria. Whenever possible, the criteria descriptions have been adjusted to make them easier to understand for materials, methods and verification for producing quality soldered interconnections and assemblies. The requirements for all three classes of construction are included. Full color illustrations are provided for clarity. This...

IPC-A-610 is the most widely used electronics assembly standard in the world. A must for all quality assurance and assembly departments, IPC-A-610F illustrates industry-accepted workmanship criteria for electronics assemblies through detailed statements reflecting acceptable and defect conditions, supported by full-color photographs and illustrations. This revision includes two new SMT termination styles, as well as changes in plated-through hole fill and BGA void criteria. Additionally, wherever possible statements were modified to make readability easier and to enhance understanding — all without eliminating any requirements.

Major topics include flex attachment, board-in-board, part-on-part, both lead-free and tin-lead criteria, component orientation and soldering criteria...

Save time and materials and make your training effort simple and consistent with this Solder Training Kit specifically designed for wires and terminals training. Contains all the materials you may need for testing, certification and even recertification.

Contains the following materials (all in Lead Free):
(5) Feet of 22 gauge wire
(5) Feet of 24 gauge wire
(5) Feet of 26 gauge wire
(5) Turret Terminals
(5) Gold Cups
(5) Bifurcated Terminals
(5) Hook Terminals
(5) Pierced Terminals

Sold individually (not as pictured), these turret terminals (Lead Free) are great for practicing wire and terminal soldering and sharpening your skills.  Create your own kit with them, or hey, buy one of ours.

Sold individually (not as pictured), these pierced terminals (Lead Free) are great for practicing wire and terminal soldering and sharpening your skills.  Create your own kit with them, or hey, buy one of ours.

Sold individually (not as pictured), these hook terminals (Lead Free) are great for practicing wire and terminal soldering and sharpening your skills.  Create your own kit with them, or hey, buy one of ours.

Sold individually (not as pictured), these gold cup terminals (Lead Free) are great for practicing wire and terminal soldering and sharpening your skills.  Create your own kit with them, or hey, buy one of ours. (.085")

Sold individually (not as pictured), these bifurcated terminals (Lead Free) are great for practicing wire and terminal soldering and sharpening your skills.  Create your own kit with them, or hey, buy one of ours.

Have your own components and just need a training board to mount them to? Then this is our most affordable plated through-hole training printed circuit board on the market today.  This board provides for all the placement of the standard components needed to evaluate skill levels in the most common through-hole assembly procedures. This is a great tool for testing the skill level of new employees, and as it contains standardized parts, it is ideal for training your workers. Contains one (1) board.

Allows for the assembly and soldering of the following:
Axial Diodes
Axial Electrolytic Capacitors
Radial Capacitors
1/4 Watt Resistors
1/2 Watt...

This specification covers qualification and performance of rigid printed boards, including single-sided, double-sided, with or without plated-through holes, multilayer with or without blind/buried vias and metal core boards. It addresses final finish and surface plating coating requirements, conductors, holes/vias, frequency of acceptance testing and quality conformance as well as electrical, mechanical and environmental requirements.

Revision D incorporates many new requirements in areas such as HASL coatings, alternative surface finishes, edge plating, marking, microvia capture and target lands, copper cap plating of filled holes, copper filled microvias and dielectric removal. For use with IPC-6011. Supersedes IPC-6012C and IPC-6016

This Addendum supplements or replaces specifically identified requirements of IPC J-STD-001, Revision F, for soldered electrical and electronic assemblies that must survive the vibration and thermal cyclic environments of getting to and operating in space. 18 pages. Released December 2014.

Looking to sharpen your soldering skills with a more realistic soldering production training kit?  Look no further. This through hole soldering kit comes with two practice boards and double, and in some cases triple, the number of components to assemble, so you can solder and hone those skills.  Also included is a complete set of terminals and wires to practice your connecting skills. The components are guaranteed solderable and shipped in static shielded bags. Buy one kit and share in a class, with plenty of components to practice with.

Contains the following materials:
(2) Through Hole Technology Boards
(10) Axial Diodes
(4) Electrolytic...

This essential industry standard provides descriptions and illustrations of electronic interconnect industry terminology to help users and their customers break down language barriers. Revision M contains over 220 new or revised terms, including new terminology for conformal coatings, potting and encapsulation processes, stencil design, statistical process control, and flexible printed board technology. Also includes commonly used industry acronyms. 123 pages. Released 2015.

Dubbed the "nightmare microsection," this full-color, 24x36-inch (60 x 90 cm) wall poster identifies 42 phenomena that can be seen in cross-sections of plated-through holes. Outstanding visual for supporting discussions of common (and not so common) phenomena. All defects are labeled and match the language used in IPC standards IPC-A-600, IPC-6012 and IPC-T-50. Use this poster as a tool to assist your staff more identify issues and effectively troubleshoot your manufacturing operation. Originally developed by the PCB industry in Europe, updated by IPC.

Now J-STD-001 Revision "F" & "G" compatible. The officially recognized soldering certification training kit for J-STD-001 operator and instructor certification.  This kit is in lead free format and contains a variety of components to allow for the evaluation and testing of students for not only initial certification, but recertification.  Enough materials to do a practice board and a final board, or buy one kit and use it for two people to recertify.

Contains the following materials (lead free):
(2) Lead Free Boards
(4) 1/4 Watt Axial Resistors
(4) T05 Transistors
(4) Transistor Standoffs
(4) Axial Diodes
(4) CKO6 Capacitors
(4) Capacitor Standoffs
(4) 16 Pin DIPs
(4) 0805 Resistors
(4) 1206...

Now J-STD-001 Revision "F" & "G" compatible. The officially recognized soldering certification training kit for J-STD-001 operator and instructor certification.  This kit contains a variety of components to allow for the evaluation and testing of students for not only initial certification, but recertification.  Enough materials to do a practice board and a final board, or buy one kit and use it for two people to recertify.

Contains the following materials:
(2) Lead Boards
(4) 1/4 Watt Axial Resistors
(4) T05 Transistors
(4) Transistor Standoffs
(4) Axial Diodes
(4) CKO6 Capacitors
(4) Capacitor Standoffs
(4) 16 Pin DIPs
(4) 0805 Resistors
(4) 1206 Resistors
(4) 1206 Capacitors
(4) 1206 MELF Diodes
*(4) 0402 Resistors
*(4) DPAKs
(2)...

This Cable-Harness Assembly Kit addresses the majority of component types that will be encountered in operational production and utilizes Mil Spec style connectors that have two sizes of contacts combined with the appropriate insertion/extraction tools.

With additional terminals, solder sleeves, and crimp lug terminations provided for broad skill development, this is a great representation of a variety of assembly applications creating operator skill needed to be a successful cable and harness builder.

Also provided is an overlay and wire list for the student to use, typical of those encountered in production operations.

This kit is used effectively in NASA Cable...

Soldering wires and/or components to mounted terminals adds a great deal of reality for production training. It is an effective method to illustrate and practice required stress relief for components and wires attached between terminals. It also allows the student to practice and demonstrate wire and lead “dress” as well as continuous run attachments.

This kit contains Bifurcated terminals that are attached to .125" laminate, so that it can be effectively held in a standard workmanship fixture.

Not only are these mounted terminals a good enhancement for training; they are the only effective way to accomplish some production principles.

Note:...

Soldering wires and/or components to mounted terminals adds a great deal of reality for production training. It is an effective method to illustrate and practice required stress relief for components and wires attached between terminals. It also allows the student to practice and demonstrate wire and lead “dress” as well as continuous run attachments.

This kit contains Turret terminals that are attached to .125" laminate, so that it can be effectively held in a standard workmanship fixture.

Not only are these mounted terminals a good enhancement for training; they are the only effective way to accomplish some production principles.

Note:...
